60KV 500PF Y5Y High voltage capacitors

Brand :HVDIODE

Product origin :CHINA

Delivery time :20 TO 30 DAYS

Supply capacity :50KK

Technical Description
All electrical characteristics were measured at an ambient temperature of 25°CDuration of withstand voltage test: 60s
The insulation resistance is measured at the rated voltage and the charging time1min
The temperature characteristics comply with the YST material standards
When installing, please ensure that M4 bolts are used and the recommended torque is applied
Avoid mechanical shock and use environments that exceed the rated temperature range
The product complies with the RoHS environmental protection standard
Service life: More than 10 years (under rated conditions)
Storage conditions: Temperature -40'C to +85'C, relative humidity ≤85%

External dimensions

D:32 mm

H:32 mm

Threaded Hole:M4

Electrical characteristics (25°C)

Parameters	Specification
Electric capacity	500 pF ±10%
Rated voltage	50 KV (DC)
Material voltage resistance	≥75 KV (DC)
Insulation resistance	≥10,000 MΩ
Dielectric loss (tanδ)	≤0.2%
Partial discharge (50KV)	≤5 pc
Operating ambient temperature	-40°C to +80°C
Temperature characteristics (material)	YST
Colour	white

Technical Description

All electrical characteristics were measured at an ambient temperature of 25°C
Duration of withstand voltage test：60s
The insulation resistance is measured at the rated voltage and the charging time1min
The temperature characteristics comply with the YST material standards
When installing, please ensure that M4 bolts are used and the recommended torque is applied
Avoid mechanical shock and use environments that exceed the rated temperature range
The product complies with the RoHS environmental protection standard
Service life: More than 10 years (under rated conditions)
Storage conditions: Temperature -40°C to +85°C, relative humidity ≤85%
