Technical Description All electrical characteristics were measured at an ambient temperature of 25°CDuration of withstand voltage test: 60s The insulation resistance is measured at the rated voltage and the charging time1min The temperature characteristics comply with the YST material standards When installing, please ensure that M4 bolts are used and the recommended torque is applied Avoid mechanical shock and use environments that exceed the rated temperature range The product complies with the RoHS environmental protection standard Service life: More than 10 years (under rated conditions) Storage conditions: Temperature -40'C to +85'C, relative humidity ≤85%

⑴Rated Voltage：DC15KV ⑵Nominal Capacitance Range:： 900PF~1100PF Test Conditions: (a) Measurement Voltage: 23 kV (b) Frequency: 1 kHz (c) Temperature: 25°C ±2°C (d) Humidity: 70% RH Inspection Method: Use rubber gloves to avoid thermal influence on capacitance accuracy. ⑶Capacitance Tolerance： k±10% ⑷Dissipation Factor (tg)：≤ 0.5% ⑸Insulation Resistance （IR）≥ 100000MΩmin ⑹Withstand Voltage Test：DC 1.5× rated voltage, no breakdown or arcing.

1. Low leakage,low power loss,high reliability. 2. Excellent Instantaneous large current shock resist features. 3. Good Reverse avalanche breakdown features 4. Tj:-40℃——+120℃ 5. Various of dimensions can be chose or customized. 6. Environmental protection ?process, be consistent with international standards
